CLW5040XLCQ4??Model technical parameters | |||
Name: | CLW5040XLCQ4 | Exterior size(mm): | 5995×1910×2790 |
Chassis: | QL10403HARY | Container size(mm): | 4100×1740×1750 |
Total weight :(kg) | 4475 | Approach angle/ Departure angle(° ) | 24/16 |
Payload:(kg) | 1495 | Front suspension/rear suspension(mm): | 1015/1620 |
Kerb Mass:(kg) | 2850(Kg) | Max Speed(km/h): | 98 |
Chassis parameters | |||
Chassis: | QL10403HARY | Axle weight: | 1800/2675 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3360 | Fronttread(mm): | 1385,1504 |
Max people in cab: | 2 | Rear tread(mm): | 1425 |
Number of tires: | 6 | Number of spring axle: | 8/6+5,4/3+2 |
Tire Type: | 7.00-15 10PR,7.00R15 10PR,7.00-16 8PR,7.00R16 8PR,195/75R16LT 8PR | ||
introduction: | 1、车厢顶部封闭,不可开启;2、选装侧门;3、侧防护材料: Q235A碳钢,后防护材料:Q235A碳钢,与后车架焊接连接,后防护断面尺寸:100×50(mm);离地高度:450mm;4、可选装新款前部灯具(前远光灯、前近光灯、前位灯、前转向灯、侧转向灯)、新款格栅、新款前面板、加宽前保险杠。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
4JB1CN | 庆铃五十铃(重庆)发动机有限公司 | 2771 | 72 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
